本篇文章探讨了大数据技术之Elasticsearch单机多实例，希望阅读本篇文章以后大家有所收获，帮助大家对相关内容的理解更加深入。

前言

团队新采购一批大内存服务器作为Elasticsaerch节点。根据ES官网文档，单机单实例最多不超64G内存，这批服务器用于单机单实例有些""大材小用"" .由于之前用docker做ES集群碰到过坑, 所以这次采用实体跑多实例的方案。

环境

ES单机多实例有两种情况,一种为单集群多实例,另外一种为多集群多实例。 本篇主要介绍单机多集群多实例的情况。

由于大多节点配置等信息都雷同，本文用两台服务器做为示例

需求架构图

部署过程

下载

node1,node2

curl -O https://artifacts.elastic.co/downloads/elasticsearch/elasticsearch-7.0.0-x86_64.rpm
rpm -ivh elasticsearch-7.0.0-x86_64.rpm

创建目录

node1,node2

mkdir -p /data/elasticsearch/{t2,t1}/{data,repo,log}chown elasticsearch. elasticsearch/ -R

拷贝配置文件

node1,node2

cd /etc/
cp -avP elasticsearch/ t1es/
cp -avP elasticsearch/ t2es/

配置文件

node1

/etc/t2es/elasticsearch.yml

cluster:
    name: t2es
    routing:
        allocation:
            same_shard.host: true
    initial_master_nodes:
        - t2-node-70
        - t2-node-71
        - ...
node:
    name: t2-node-70
    master: true
    data: true
    max_local_storage_nodes: 2path:
    data: /data/elasticsearch/t2/data
    logs: /data/elasticsearch/t2/log
    repo: /data/elasticsearch/t2/repo
network:
    host: t2-node-70http:
    port: 9200transport.tcp.port: 9300discovery.zen.ping.unicast.hosts: [""t2-node-70:9300"",""t2-node-71:9300"" ...]
discovery.zen.fd.ping_timeout: ""10s""discovery.zen.fd.ping_retries: 10reindex.remote.whitelist: ""192.168.1.*:*""

/etc/t1es/elasticsearch.yml

cluster:
    name: t1es
    routing:
        allocation:
            same_shard.host: true
    initial_master_nodes:
        - t1-node-70
        - t1-node-71
        - ...
node:
    name: t1-node-70
    master: true
    data: true
    max_local_storage_nodes: 2path:
    data: /data/elasticsearch/t1/data
    logs: /data/elasticsearch/t1/log
    repo: /data/elasticsearch/t1/repo
network:
    host: t1-node-70http:
    port: 9201transport.tcp.port: 9301discovery.zen.ping.unicast.hosts: [""t1-node-70:9301"",""t1-node-71:9301"" ...]
discovery.zen.fd.ping_timeout: ""10s""discovery.zen.fd.ping_retries: 10reindex.remote.whitelist: ""192.168.1.*:*""

node2

/etc/t2es/elasticsearch.yml

...network:
    host: t1-node-70http:
    port: 9201transport.tcp.port: 9301...

/etc/t1es/elasticsearch.yml

...network:
    host: t1-node-70http:
    port: 9201transport.tcp.port: 9301...

启动服务配置

node1,node2

cd /usr/lib/systemd/system
cp -avp elasticsearch.service  t2es.servicecd /etc/sysconfig
cp -avp cp -avP elasticsearch  t2es
cp -avp cp -avP elasticsearch  t1es

修改启动服务配置

node1,node2

/usr/lib/systemd/system/t2es

[Unit]Description=t2-ElasticsearchDocumentation=//www.elastic.coWants=network-online.targetAfter=network-online.target[Service]RuntimeDirectory=elasticsearchPrivateTmp=trueEnvironment=ES_HOME=/usr/share/elasticsearchEnvironment=ES_PATH_CONF=/etc/t2esEnvironment=PID_DIR=/var/run/elasticsearchEnvironment=ENV_PATH=/etc/sysconfig/t2es
# EnvironmentFile=-/etc/sysconfig/elasticsearch  WorkingDirectory=/usr/share/elasticsearchUser=elasticsearchGroup=elasticsearchExecStart=/usr/share/elasticsearch/bin/elasticsearch -p ${PID_DIR}/t2es.pid --quietStandardError=inheritLimitNOFILE=65535LimitNPROC=4096LimitAS=infinityLimitFSIZE=infinityTimeoutStopSec=0KillSignal=SIGTERMKillMode=processSendSIGKILL=noSuccessExitStatus=143[Install]WantedBy=multi-user.target

/usr/lib/systemd/system/t1es

...
Environment=ES_PATH_CONF=/etc/t2es
Environment=PID_DIR=/var/run/elasticsearch
Environment=ENV_PATH=/etc/sysconfig/t2es
# EnvironmentFile=-/etc/sysconfig/elasticsearch  WorkingDirectory=/usr/share/elasticsearch
User=elasticsearch
Group=elasticsearch
ExecStart=/usr/share/elasticsearch/bin/elasticsearch -p ${PID_DIR}/t2es.pid --quiet
...

编辑/usr/share/elasticsearch/bin/elasticsearch-env

修改 source /etc/sysconfig/elasticsearch

if [ ! -z ${ENV_PATH} ]then    source ${ENV_PATH} else    source /etc/sysconfig/elasticsearchfi

/etc/sysconfig/t2es

所有参数配置可以在这里面加

ES_PATH_CONF=/etc/t2esES_STARTUP_SLEEP_TIME=5

启动

node1,node2

systemctl t1es startsystemctl t2es start

总结

• Elasticsearch 7.x系列需要配置initial_master_nodes.

• cluster.routing.allocation.same_shard.host防止一台主机存在多个相同切片.

• node.max_local_storage_nodes配置一台主机可以存在的实例数量.

"
